Alfamarine 140

ДВИГАТЕЛИ:
2 x 2775hp MTU 12V 4000 M90
Часы наработки: 3639 aprox.

СКОРОСТЬ:
Максимальная:     17 knots aprox.
Круизная: 10 knots aprox.

ДАЛЬНОСТЬ ПЛАВАНИЯ НА КРУИЗНОЙ СКОРОСТИ:
2000 nautical miles

ВМЕСТИМОСТЬ:
ТОПЛИВНЫЙ БАК:    30000 Litres
БАК ПРЕСНОЙ ВОДЫ:   7200 Litres
СТОЧНЫЙ БАК: 4800 Liters

МЕХАНИЧЕСКОЕ ОБОРУДОВАНИЕ:
Kohler 80kW generators (2) 3485 and 3499 hrs
Kohler 66kW generator
Idromar 600 l/h watermakers (2)
Rotor 4RN2 50kW bowthruster
ZF gear boxes with V-drive transmission and 4-blades propellers
Radice propellers 4 fixed blades
Koopnautic zero speed stabilizers
Hamann sewage treatment plant
DVZ oil/water separator and Alfa Laval fuel treatment
Condaria 480.000 BTU air conditioning
Voltage: 380V-3 phase, 220V 50 Hz
Electricity
Electricity 100 kw Frederico Landucci inverter 220V/24V
Batteries 75 Amp + 75 Amp + 25 Amp
Mastervolt battery chargers
2 x 300 liters 3 kw Gianneschi boilers
13 Vacu-Flush fresh water toilets.
Consumptions: 900 l/h at 17 knots / 300 l/h at 13 knots / 150 l/h at 10 knots
Ranges: 1000 nautical miles at 13 knots / 2000 nautical miles at 10 knots
Gasoil tanks: 30,000 liters
Fresh water tanks: 7,200 liters
Grey water holding tanks: 1,400 liters
Black water holding tanks: 700 liters

РАЗМЕЩЕНИЕ:
Berths: 16
Cabins: 8
Head: 8
Crew Berths: 10
Crew Cabins: 5

Main Deck
Forward: full-beam master cabin with walk-in wardrobes, bathroom with separate toilet, bath/Jacuzzi, shower/steam room; additional single cabin in master cabin with own bathroom (bath/Jacuzzi), separate master dining area
Amidships: port side laundry and galley, starboard side day head, staircases to bridge deck and lower deck
Aft: dining table leading into main salon, leading out to main deck aft

Lower Deck
Port side:
Guest cabin with twin beds forward
Guest cabin with three single beds amidships
Double VIP cabin aft

Starboard side:
Double guest cabin forward
Guest cabin with twin beds amidships
Double VIP cabin aft
All cabins with en-suite showers

Upper Deck
Bridge command forward, captains cabin to port, ship's office to starboard, master office aft to port
Starboard side corridor, aft disco leading out to bridge deck, large guest dining table aft with cushioned seating areas

ВНУТРЕННЕЕ ОБОРУДОВАНИЕ:
Entertainment Equipment
Sony Hifi system with CD/DVD players throughout
Seatel 4006 Sat TV system
Plasma flat screen TVs in the saloon, lounge and master stateroom
LCD flat screen TV’s in vip cabins, guest cabins, captain cabin and crew mess

КАМБУЗ / ПРАЧЕЧНОЕ ОБОРУДОВАНИЕ:
Miele cooking plate
Miele oven
Whirlpool hood
Whirlpool microwave
2 Whirlpool fridges
2 Whirlpool freezers
Miele dish washer
Miele washing machines
2 Miele dryers

НАВИГАЦИОННОЕ ОБОРУДОВАНИЕ:
Communications Equipment
JRC NCR330 weatherfax
Sailor C4900 + Sailor RT422 VHF radios
Sailor HC4500 SSB radio
Sailor TT3020 satellite radio
Standard C communication system
Saab AIS
Navigation Equipment
C-Plath SR180 gyroscopic compass
JRC FF50 deph sounder
JRC Nav500 GPS
JRC Plot700FX Chart plotter
C-Plath autopilot
Decca radar
HP Navigation computer

ОБОРУДОВАНИЕ ПАЛУБЫ:
Teak decks
SHHP pool TW-anchor 272kg anchors (2)
2 x 3500W Lofrans windlasses
Sanguineti-Chiavari passarelle
Sanguineti-Chiavari bathing ladder
Flybridge sunbathing area with sofa and Jacuzzi
Split-level above Jacuzzi bimini top
Tender area with 1000kg Sanguineti-Chiavari hydraulic crane for tender on flybridge

AВАРИЙНО-СПАСАТЕЛЬНОЕ ОБОРУДОВАНИЕ:
Fire and bilge flood monitoring alarm systems
Sea fire-fighting system and extinguishers
Automatic bilge pumps and manual bilge pumps
Complete safety equipment with 4 Zodiac life rafts for 6 people
Horn
Barometer
EPIRB satellite beacon (Emergency Position Indicating Radio Beacon)

ТЕНДЕРЫ И ВОДНОЕ СНАРЯЖЕНИЕ:
Zodiac Tender with Yamaha 70hp outboard
Jetski for 2 persons- Yamaha, max 160kg,352 IDS

РЕМОНТ И ТЕХОБСЛУЖИВАНИЕ:
Works carried out,
•Haul out, for full ABS hull inspection.
•Shafts rudders and propellers removed inspected and replaced with new seals and bearings.
•Hull plate inspection, new section added under engine room 2mx2m.
•Anti-fouled and anodes replaced.
•Prop speed painted on shafts, propellers and bowthruster.
•All tanks emptied cleaned and inspected all new gaskets.
•Black and grey water tanks painted Interline 704.
•Freshwater tank painted Interline 925.
•Ballast tanks cleaned and painted Interline 925.
•New generator switchboard, Easygen 3500 touch screen control.
•Tank sensors installed and integrated into main engine room switchboard.
•Hamman sewage treatment plant service.
•Water maker’s service. (some piping required replacement )
• Machinery valves removed replaced, overhauled as necessary.
•Kohler generators serviced, emergency generator serviced, Generators load tested as required by ABS.
•Main engine gearboxes serviced.
•Grey and black water pumps serviced.
•Fresh and seawater cooling pumps serviced.
•Bilge, fire fighting and deck wash pumps serviced.
•Bilge and fire pneumatic valves service.
•Bow thruster service.
•Mega test of electric motors, main switchboard engine room and bridge.
•Air conditioning central units serviced
•Air conditioning fancoil units serviced (48 in total )
•Renewal of manifolds at fancoil piping system.
•Fuel purifier service
•Bilge Separator service
•Two new hot water tanks installed.
•Improve CO2 release system at request of ABS surveyor.
•Dismount Main engine exhaust spray rings for ABS surveyor.
•All portholes and aft quarters grinded and blisters repaired & repainted.
•Engine room & bridge doors grinded and blisters repaired & painted
•Replace section of teak on bridge deck aft to include scuppers to stop water sitting on deck.
•All teak decks sanded caulking replaced as required.
•All LSA and FFE equipment sent for annual service.
•Tender and jet skis serviced for summer season.
•New transas Navi-sailor 4000 ECDIS.
•Yachtspot marine wifi unit installed.
This is only a brief outline of an extensive refit period carried out by the Owner and crew
Refit in 2017
•Interior furniture upgrades
•New carpets
•Interior upgrades

Naval architecture Andrea Bacigalupo
Interior design Jim Collins
Gross Tonnage 429 tones

КОММЕНТАРИИ БРОКЕРА:
A modern, high-performance, all-aluminium superyacht designed by Andrea Bacigalupo and built to MCA compliance by Cantieri di Fiumicino in 2003. One of the yard's Alfamarine series, she has a warm and inviting interior featuring richly coloured fabrics and soft wood finishes. Accommodation is for as many as 16 guests in eight cabins including a full-beam master cabin on the main deck. There are also three double staterooms along with two twins, a triple and a single, all with state-of-the-art audio-visual systems and all with en-suite bathrooms. Very generous outdoor deck areas. Twin 2.755hp MTU engines give her a cruising speed of 13 knots. Offered ready for her new owner. Price not negotiable

МЕСТОНАХОЖДЕНИЕ:
Philippines
